GDSL-BX-100 Primary Current Injection Test Set
Specification
● Power supply: AC 220V 50Hz.
● Output power: 3kVA.
● Output current: 500A in series,1000A in parallel.
● Output voltage: 6V in series, 3V in parallel.
● Current can be adjusted smoothly and continuously. The accuracy is 1.0%.
● Output current is standard sine wave, waveform distortion is less than 5%.
● Output current: RMS continuous adjustable.
● Duty Cycle: 5mins ON, 10mins OFF.
